WHITE OAK HARDWOOD IDENTIFICATION GUIDE

WHITE OAK HARDWOOD IDENTIFICATION GUIDE

An In-Depth Look at White Oak’s Characteristics, Color, Grain & More

WHITE OAK

OTHER COMMON NAMES

White oak is sometimes referred to as American white oak, northern or southern white oak, stave oak, or fork-leaf white oak.[5] [9]

LATIN NAME

White Oak’s scientific name is Quercus alba, which means ‘the white oak’. [3]

CHARACTERISTICS - WHITE OAK

Freshly cut white oak has a distinct look and smell with a coarse grain pattern that is highly recognized and often selected by woodworkers.

Coming from natural forests in North America, white oak lumber is sought after in many export markets because of its superior finishing properties.[3] White oak sapwood is creamy, white to light brown, whereas the heartwood is light brown to medium brown with gray or olive hues.[3] However, sapwood and heartwood can blend and become harder to distinguish.



MAIN USES - WHITE OAK

Described as exceptionally valuable, American white oak is unique to North America. It is grown throughout different regions which has led to many varieties of white oak depending on the location of growth.[5] Because of its wide availability, the price point of this species can be an economical option, especially when compared to other domestic hardwoods like hickory, walnut and cherry.

White oak works well with all stains to create a beautiful finish. It glues well, but the type of glue used for woodworking projects should be chosen with care. Casein glue causes a chemical reaction and will not properly adhere because of white oak’s high tannic acid content.[2]

Common applications of white oak lumber include doors, furniture, hardwood flooring, cabinetry, paneling, plywood, veneer, boat building, barrels, and interior moulding and trim.[5]

DOWEL ROD
FURNITURE
FLOORING
CABINETRY
MOULDINGS & TRIM

MILLING

White oak trees are known for strength and durability, making them a preferred selection for structural projects.[5] Oak wood has high moisture content and low density, which results in relatively high volumetric shrinkage (16%).[3]

White oak wood must be dried carefully and slowly to avoid damage, discoloration, or degradation.[3] In humid conditions or regions, it can be difficult to achieve a pristine product, so a kiln is essential. White oak lumber is typically kiln dried from green to 6% moisture in 4-6 weeks, depending on the thickness. [5]

White oak lumber can be cut in one of three ways: flat sawn, quarter sawn, or rift sawn.

When the log is cut at the sawmill, each type of cut is dependent on the orientation of the log. For woodworkers, it is also suitable for tight cooperage.

Flatsawn is the most common cut of lumber available and the least expensive to be manufactured from log to lumber. The wood has a cathedral pattern on the face of the board where the annular rings are 30 degrees or less.[6]

Quartersawn is more expensive than flat sawn but has a distinct, straight grain pattern that is defined by the angle of the wood being sawn. The log is cut into four quarters, and the annular growth rings intersect on the face of the board at a 60 to 90 degree angle, hence the name.[6]

Riftsawn is the most expensive and least common because it produces the most waste. Rift sawn lumber has a unique linear pattern because it is milled perpendicular to the optimal 45 degree angle annual growth rings.[6]


HARDWOOD PROPERTIES - WHITE OAK

The workability of white oak requires the use of power tools but it responds well to steam-bending, compression, staining, painting and drilling (although it is recommended to pre-bore). White oak lumber is also rot-resistant and its workability makes it a popular choice for many projects. (Keep in mind that white oak hardwood should not be sanded in an orbital direction because the circular marks are hard to remove).

Overall, the popularity of white oak is due to the species’ hardness, durability and affordable pricing, relative to other hardwood lumber species. On the Janka Hardness Scale, white oak sits at 1350, which makes it one of the toughest woods on the market.

But, while the hardness results in great structural applications, it is not ideal for carvers or dull cutting edges. While cutting, a slow feed rate and shallow passes will ensure no splintering or ripping.

One characteristic that sets white oak heartwood apart from other hardwood species is the cellular make-up of the wood. It contains tissues called tyloses that clog up the cells from aerating, therefore making the wood waterproof[6]. This is why white oak is ideal for wooden barrels for wineries or boat building[3].

Janka Hardness Scale


ENVIRONMENTAL PROFILE - WHITE OAK

American white oak is very sustainable and is found uniquely across northern and southern North America. It does not have any population threat and is widely available in natural forests along the tops of the Appalachian ridges to the low country areas in the South.[5]

White oak trees usually prefer deep, well-drained, moist soil, and the largest trees are often found along the eastern coastal states like Delaware and Maryland. They can adapt to a variety of soils, but they are intolerant to shallow or alkaline soils. They are difficult to transplant and do not respond well to root disturbance.[4]

White oak trees can reach heights of 60 to 90 feet with a diameter of 3 to 5 feet. They will reach maturity around 20 years, at which point they will begin to produce acorns.[6]

The white oak tree can be easily identified by the shapes of the leaves—they are round lobed (red oak leaves are pointed).

If the leaves have dropped, a white oak can be identified by the characteristics of its lighter ashy-colored bark. White oak trees grow at a slower rate but can live for centuries. They have a short, stocky trunk with many thick, large branches extending out horizontally.[4]

Volume of live trees on forest land, 1000 m3

All data derives from Forest Inventory Data Online (FIDO), a component of the U.S. Forest Service Inventory and Analysis Program (FIA). Data was compiled by AHEC in January 2016 using the most recent state inventory available (2014 for most states). "Forest volume" refers to "net volume of live trees on forest land," as defined by FIA (see glossary). FIA forest volume data is available for 49 U.S. states (Hawaii and Washington D.C. are omitted) with total hardwood forest volume of 18.1 billion m3 of which 13.5 billion m3are commercially significant.


WHITE OAK PRODUCTS AT BAIRD BROTHERS

Baird Brothers Fine Hardwoods is happy to assist with any questions you have about our white oak products, which include a variety of White Oak mouldings, White Oak S4S lumber, White Oak plywood, Quarter Sawn White Oak plywood, White Oak flooring and other items.



Please call 1-800-732-1697 or Contact Us if you need help with our extensive inventory.


COMPARISON TO OTHER WOOD SPECIES

Source: The Department of Agriculture's Wood Handbook

LumberSpecific GravityJanka HardnessModulus of Elasticity (MPa)Impact Bending (mm)Grain
African Mahogany --- 830 lb 9,700 --- Medium/Coarse
Alder 0.41 590 lb 9,500 510 Fine
Ash 0.6 1,320 lb 12,000 1,090 Fine
Basswood 0.37 410 lb 10,100 410 Fine
Beech 0.64 1,300 lb 11,900 1,040 Fine/Medium
Birch, Yellow 0.62 1,260 lb 13,900 1,400 Fine
Cedar, Western Red 0.32 350 lb 7,700 430 Fine
Cherry, Brazilian 0.91 2,350 lb 22,510 --- Medium
Cherry 0.5 950 lb 10,300 740 Fine
Cypress 0.51 510 lb 6,300 --- Medium
Douglas Fir 0.48 710 lb 12,300 660 Medium/Coarse
Hemlock 0.4 540 lb 8,300 530 Coarse
Hickory 0.66 1,820 lb 11,900 1,120 Medium
Maple, Hard 0.63 1,450 lb 12,600 990 Fine
Maple, Soft 0.47 700 lb 7,900 640 Fine
Oak, Red 0.63 1,290 lb 12,500 1,090 Coarse
Oak, White 0.68 1,360 lb 12,300 940 Coarse
Pine, Eastern White 0.35 380 lb 8,500 460 Medium
Pine, Ponderosa 0.4 460 lb 8,900 480 Medium
Pine, Yellow (Shortleaf) 0.51 690 lb 12,100 840 Fine/Medium
Poplar 0.42 540 lb 10,900 610 Medium
Sapele 0.67 1,410 lb 15,930 --- Fine
Teak 0.66 1,070 lb 10,700 --- Coarse
Walnut (Black) 0.55 1,010 lb 11,600 860 Medium

*Data is based on a moisture content of 12%.

GLOSSARY

Impact Bending — In the impact bending test, a hammer of given weight is dropped upon a beam from successively increased heights until rupture occurs or the beam deflects 152 mm (6 in.) or more. The height of the maximum drop, or the drop that causes failure, is a comparative value that represents the ability of wood to absorb s hocks that cause stresses beyond the proportional limit.

Janka Hardness — Defined as resistance to indentation using a modified Janka hardness test, measured by the load required to embed a 11.28-mm (0.444-in) ball to one-half its diameter. Values presented are the average of radial and tangential penetrations.

Modulus of Elasticity — Elasticity implies that deformations produced by low stress are completely recoverable after loads are removed. When loaded to higher stress levels, plastic deformation or failure occurs.

Specific Gravity - A measure of the ratio of a wood's density as compared to water. If a wood species had the same density as water, the specific gravity would be 1.00.


SOURCES

  1. “Wood Handbook, Wood as an Engineering Material”. fpl.fs.fed.us. April 2010. Accessed Mar. 2021.
  2. “White Oak”. WoodMagazine.com. Accessed Mar. 2021.
  3. “White Oak”. The Wood Database. Wood-database.com. Accessed Mar. 2021.
  4. “White Oak”. Arbor Day Foundation. Arborday.org. Accessed Mar. 2021.
  5. “American White Oak”. American Hardwood Export Council. Americanhardwood.org. Accessed Mar. 2021.
  6. “Oak Wood”. Vermontwoodsstudios.com. Accessed Mar. 2021.
  7. "Janka Hardness Scale" Bairdbrothers.com
  8. “Quercus alba, White Oak”. Silvics of North America, Vol 2. Srs.fs.usda.gov. Accessed Mar 2021.
